factory aluminum led slim panel light housing SKD 3w 6w 9w 12w 15w 18w 24w

Product Description

Product Description These led ceiling light fixtures produced by SHCET adopt a backlit design technique, and this light technology is a new type of
energy saving lighting. The LED ceiling light fixture features good color consistency, multi-color temperature, high luminance,
long use age, energy saving and environmental, thus ensuring LED ceiling light fixture can replace traditional lighting systems.
The LED ceiling light fixture can be widely used in hotels, offices, residences and conference rooms. The LED ceiling light
fixture is made of a shell body, light source, light guide plate, diffuser plate and reflective sheeting. The light strip is
around the shell body and aids the light to have special lighting effect. Product Paramenters
Model
CET-120R-9W
CET-120R-18W
CET-120R-24W
CET-120R-36W
Lamp Power
9W
18W
24W
36W
Lamp Diameter
Φ93*H25mm
Φ123*H25mm
Φ175*H25mm
Φ228*H25mm
Cut Out Size
Φ70mm
Φ100mm
Φ150mm
Φ200mm
Lamp Material
PC+AL
Shine Angle
180°
IP Rating
IP40
SPD
2.5KV
LED Chips Model
2835SMD
CRI
70-75 Or 80-85
Power Factor
0.6-0.7 Or 0.9-0.97
Input Voltage
AC85-277V
Body Color
white;
Color Temperature
3000-3500K; 4000-4500K; 6000-6500K;
Certificates
BIS ,SASO ,LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001
Model
CET-120S-9W
CET-120S-18W
CET-120S-24W
CET-120S-36W
Lamp Power
9W
18W
24W
36W
Lamp Diameter
L93*W93*H25mm
L123*W123*H25mm
L175*W175*H25mm
L228*W228*H25mm
Cut Out Size
L70*W70mm
L100*W100mm
L150*W150mm
L200*W200mm
Lamp Material
PC+AL
Shine Angle
180°
IP Rating
IP40
SPD
2.5KV
LED Chips Model
2835SMD
CRI
70-75 Or 80-85
Power Factor
0.6-0.7 Or 0.9-0.97
Input Voltage
AC85-277V
Body Color
white;
Color Temperature
3000-3500K; 4000-4500K; 6000-6500K;
Certificates
BIS ,SASO ,LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001
Model
CET-ZQ1-20W
CET-ZQ2-40W
CET-ZQ3-48W
CET-ZQ4-48W
CET-ZQ5-48W
CET-ZQ6-96W
CET-ZQ7-48W
Lamp Size
300x300*30mm
295*295*30mm
300x600*30mm
295*595*30mm
600x600*30mm
595*595*30mm
600*600*20mm
595*595*20mm
300*1200*30mm
295*1195*30mm
600*1200*30mm
595*1195*30mm
620*620*30mm
Lamp Power
20W
40W
48W
48W
48W
96W
48W
Shine Angle
180°
IP Rating
IP40
SPD
2.5KV
Lamp Material
AL+IRON
CRI
80-85
Power Factor
0.6-0.7 Or 0.9-0.97
Input Voltage
AC85-277V Or AC165-265V
Body Color
white;
Color Temperature
3000-3500K; 4000-4500K; 5000-5500K;6000-6500K;
Certificates
BIS ,SASO ,LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001
Model
CET-ZQS1-20W
CET-ZQS2-40W
CET-ZQS3-48W
CET-ZQS4-48W
CET-ZQS5-48W
Lamp Size
300x300*30mm
300x600*30mm
600x600*30mm
600*600*20mm
300*1200*30mm
Lamp Power
20W
40W
48W
48W
48W
Shine Angle
180°
IP Rating
IP40
SPD
2.5KV
Lamp Material
AL+IRON
CRI
80-85
Power Factor
0.6-0.7 Or 0.9-0.97
Input Voltage
AC85-277V Or AC165-265V
Body Color
white;
Color Temperature
3000-3500K; 4000-4500K; 5000-5500K;6000-6500K;
Certificates
BIS ,SASO ,LVD-EMC,RoHs ,IES ,TUV, EAC, ISO9001
